Create a private and beautiful outdoor oasis with our 5 ft 5 top vinyl picket privacy fence. Similar to our popular 5ft Tall White Closed Vinyl Picket Privacy Fence, this fence provides superior privacy by blocking unwanted views while enhancing your property’s curb appeal. Easy to install and maintain, it’s perfect for homes, gardens, and commercial spaces.
Built to last, this fence features exceptional weather, corrosion, and UV resistance, ensuring long-lasting color and preventing warping. Its robust construction includes a reinforced bottom rail with aluminum alloy for added strength and stability. The interlocking groove design and mortise and tenon joints of the precision-molded panels (8 panels per set, 287 x 22.3 x 925mm, 1.3mm wall thickness) guarantee a secure and structurally sound installation.
The scientific 3-rail structure (Top: 50.8 × 88.9 × 2388mm, 2.8mm wall thickness; Bottom & Middle: 50.8 × 152.4 × 2388mm, 2.8mm wall thickness) further enhances durability. Finished with symmetrically distributed, elegant top pickets (38.1 x 38.1 x 320mm, 2mm wall thickness), this fence adds a touch of sophistication to any landscape.
As a leading fence manufacturer, we offer standard sizes and colors, as well as custom solutions tailored to your specific needs. Contact us to discuss your project’s unique requirements, including size, color, and installation options.
| Item | Dimension(mm) | Thickness(mm) | Qty |
| Top Rail | 50.8×88.9× 2388 | 2.8 | 1 |
| Middle Rail | 50.8×152.4× 2388 | 2.8 | 1 |
| Bottom Rail | 50.8×152.4× 2388 | 2.8 | 1 |
| Picket | 38.1×38.1×320 | 2 | 5 |
| U-Channel | 854 | 1.2 | 2 |
| Panel | 287×22.3×925 | 1.3 | 8 |
| Alum | 2388 | 1 | |
| Post | 127×127×2200 | 3.8 | 1 |
| PVC Posts and Post Caps are not included in each section. Please order separately. | |||
 |
 |
 |
| Arbor Caps | External Flat Cap | Flat Cap |
 |
 |
 |
| Gothic Cap | Sharp Point Cap | New England Cap |
PVC resin is combined with a proprietary blend of additives in a high-shear mixer, ensuring homogeneous dispersion and optimal material properties.
The formulated PVC compound is fed into a single- or twin-screw extruder, where it is plasticized and forced through a profile die. Cooling is achieved via water bath or air cooling, followed by controlled traction to maintain dimensional stability.
Extruded profiles are automatically cut to specified lengths using precision cutting equipment, ensuring consistent component dimensions.
CNC milling equipment is employed to create precise holes, slots, and other features required for assembly, adhering to strict tolerances.
Components are subjected to a multi-stage cleaning process, including degreasing and rinsing, to remove surface contaminants and ensure optimal adhesion for any subsequent coatings or treatments.
Trained technicians assemble the fence components using specialized jigs and fixtures, ensuring proper alignment and secure fastening.
Each assembled fence undergoes a comprehensive inspection, including dimensional verification, visual inspection for defects, and functional testing of hardware.
Finished fence components are carefully packaged using appropriate materials and methods to prevent damage during storage and transportation.
